1319-Z75
Diameter: 13.44±0.02mm
Height: 19.05±0.05mm
Table height: 7.5±0.2mm
Impact: 45 J×10 times
VTL: >150
High- temperature Resistance: 750 °C 10 min
1319-Z90
Diameter: 13.44±0.02mm
1928-R10
Height: 19.05±0.05mm
Table height: 7.5±0.2mm
Impact: 45 J×10 times
VTL: >150
High- temperature Resistance: 750 °C 10 min
Diameter: 19.05±0.02mm
Height: 28.20±0.05mm
Table height: 10.0±0.2mm
Impact: 50 J×10 times
VTL : >30-50
High- temperature Resistance: 750℃ 10 min
